PRODUCT DATASHEET
Luxa Tela 100 Zip Screen Blinds
PRODUCT DATASHEET
Luxa Tela 100 Zip Screen Blinds
Motorised zip-guided exterior screen with whisper-quiet motor.
Key features
- Whisper-quiet motor system
- Zip-guided channels with integrated zipper
- Natural light with privacy
- Sun, wind and weather protection
- Precision fabric tension adjustment
- Easy assembly and maintenance access
- Covered panel design
- Sliding side connections
- Plastex high-quality accessories
- Max area 12.5 m²
Technical specifications
| Operation | Motorised (whisper-quiet motor) |
| Guide System | Zip-guided with integrated zipper |
| Fabric | Balanced — natural light in, blocks outside visibility |
| Dimensions (X) | 900 – 4,000 mm |
| Dimensions (Y) | 500 – 3,500 mm |
| Max Area | 12.5 m² |
| Max Expansion | 3,500 mm |
| Note | Heights above 2.7m: fabric has additional markings |
| Accessories | Plastex high-quality components |
| Assembly | Covered panel design, sliding side connections |
| Tension System | Curtain tension PVC profile with precision adjustment |
Standards & certifications
- EN 1991-1-1 · Densities, self-weight, imposed loads
- EN 1991-1-3 · Snow loads
- EN 1991-1-4 · Wind actions
- EN 1090-3 · Execution of aluminium structures
- EN 12020-2 · Aluminium extrusion tolerances
- Qualicoat Class 2 · TIGER Coatings powder coat
- EN AW-6063-T5 · Aluminium alloy / temper
- ISO 9001 · Manufacturer quality management
Warranty
10 years on aluminium frame · 5 years on TIGER powder coat · 5 years on motorised drive (where fitted). Conditions: install within 12 months of delivery, follow installation manual, observe rated wind/snow loads.
Order & support
PONARC Group · Sales: info@luxashade.com · Specifiers / architects: support@ponarc.com · Available across DE / AT / CH / NL / BE / FR / IT / RO / RU / SE / DK.
